6260352800
6260352800
Артикул:
6260352800
В наличии
Характеристики
AN Clearance angle major
8 Degree
CBMD Chip breaker manufacturers designation
-G12
CECC Cutting edge condition code
F - Sharpedged
COATN Coating
K10
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
3.8 mm
Delivery state valid from
10/1/2021
EPSR Insert included angle
60 Degree
FamilyProducts
HM-DREHWENDEPLATTE
IC Inscribed circle diameter
8.2 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-01 - Triangle insert
L Cutting edge length
13.62 mm
Name Identifying order number
6260352800
RE Corner radius
0.5 mm
S Insert thickness
3 mm
TCINS Tolerance class insert
H
Working process
No working processes available
