35B6D063006F0R00
35B6D063006F0R00
Артикул:
3058035
В наличии
Характеристики
BI Block index
1
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CWN Cutting width minimum
6 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
63 mm
DCP Data chip provision
0 - Without data chip
Delivery state
NL - Discontinued
DHUB Hub diameter
30 mm
DIN
FDA01602200
FamilyProducts
Slot Mill 35B6D...F 6 mm cutting width
HAND Cutting direction
R - Right
ID Technical product number
3058035
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISISO B Indicator for ISO cutting plate Pos.B
0
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-01 BI Block index
1
LOC-01 MIID Master insert identification
313
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
IL-WSP-91
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
IL-WSP-91
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA01602200
MIID Master insert identification
313
Name Identifying order number
35B6D063006F0R00
OAL Overall length
32 mm
Working process
No working processes available
WT Weight of item
0.18 kg
ZEFP Peripheral effective cutting edge count
9
