70386712
70386712
Артикул:
70386712
В наличии
Характеристики
AN Clearance angle major
7 Degree
CECC Cutting edge condition code
E - Rounded
COATN Coating
CTCP425
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
5.3 mm
Delivery state valid from
10/1/2021
EPSR Insert included angle
88 Degree
FamilyProducts
HM-DREH-BOHRWENDEPLATTE
IC Inscribed circle diameter
17.5 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-05 - Parallelogram-shaped insert
L Cutting edge length
17.5 mm
Name Identifying order number
70386712
RE Corner radius
0.8 mm
S Insert thickness
5.56 mm
Working process
No working processes available
