Главная Каталог продукции Toolunited 11 303-06 - Ball-nosed end mill GSXB20350ACB20

GSXB20350ACB20

Артикул: 212253

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

11 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

GSX

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

7 mm

DCONMSLD Shank diameter lower limit

-0.006 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

6/1/2021

DIN

ZYL00800105

FamilyProducts

GSXB20350ACB20

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

ACB20

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

ID Technical product number

212253

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LF Functional length

90 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYL cylindrical shank

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03 TCDCONCDMS Tolerance class coded

h$05

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00800105

LPR Protruding length

26.9 mm

LS Shank length

68.1 mm

MILTTY Mill tool type ISO

L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°

Name Identifying order number

GSXB20350ACB20

OAL Overall length

90 mm

PRFRAD Profile radius 1

3.5 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FFO - Die milling,FNB - Slotting,FNU - Groove milling

WT Weight of item

0.044 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
