Главная Каталог продукции Toolunited 11 303-06 - Ball-nosed end mill GSBN202001606ACZ20W

GSBN202001606ACZ20W

Артикул: 211346

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

3 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

4 mm

DCONMSLD Shank diameter lower limit

-0.005 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

6/1/2021

DIN

ZYL00600105

DN Neck diameter

3.9 mm

FamilyProducts

GSBN202001606ACZ20W

FHA Flute helix angle

25 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

ACZ20W

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

ID Technical product number

211346

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LF Functional length

65 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600105

LPR Protruding length

26.9 mm

LS Shank length

44.1 mm

MILTTY Mill tool type ISO

L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°

Name Identifying order number

GSBN202001606ACZ20W

OAL Overall length

65 mm

PRFRAD Profile radius 1

2 mm

Working process

FFO - Die milling,FNB - Slotting,FNU - Groove milling

WT Weight of item

0.01 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
