Главная Каталог продукции Toolunited 11 401-01 - Converter, rotationally symmetric HSKA100QCT19SA79

HSKA100QCT19SA79

HSKA100QCT19SA79 HSKA100QCT19SA79 HSKA100QCT19SA79

HSKA100QCT19SA79

Ingersoll
Артикул: 4553723
В наличии
В корзину
Описание
Характеристики
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SWB
CCUWS Connection code unit base
0
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0190
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DF Flange diameter
36 mm
DIN
HSK10000185
FamilyProducts
HSK-A 50/63/80/100 Quick change tapping chuck
HAND Cutting direction
N - Neutral
ID Technical product number
4553723
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SWB Quick change adapter BILZ
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0190
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SWB01900115
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
IL-K-1292
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
1000
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK10000185
LPR Protruding length
50 mm
Name Identifying order number
HSKA100QCT19SA79
OAL Overall length
79 mm
WT Weight of item
3.9 kg
