Главная Каталог продукции Toolunited 11 401-01 - Converter, rotationally symmetric FITBOREHSKA63EM40

FITBOREHSKA63EM40

FITBOREHSKA63EM40 FITBOREHSKA63EM40 FITBOREHSKA63EM40

FITBOREHSKA63EM40

Ingersoll
Артикул: 4502467
В наличии
В корзину
Описание
Характеристики
BD Body diameter
72 mm
CCFWS Connection code form
13
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0400
DCONWS Diameter
40 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
HSK06300195
FamilyProducts
HSK-A 63 End Mill Whistle-Notch adjustable
HAND Cutting direction
N - Neutral
ID Technical product number
4502467
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
116 mm
LOC-01 CCFWS Connection code form
13
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0400
LOC-01 DCONWS Diameter
40 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL04001315
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300195
LPR Protruding length
142 mm
Name Identifying order number
FITBOREHSKA63EM40
OAL Overall length
174 mm
WT Weight of item
3.3 kg
