Главная Каталог продукции Toolunited 11 401-01 - Converter, rotationally symmetric FBD060CAP250SA017

FBD060CAP250SA017

FBD060CAP250SA017 FBD060CAP250SA017 FBD060CAP250SA017

FBD060CAP250SA017

Ingersoll
Артикул: 4555248
В наличии
В корзину
Описание
Характеристики
BD Body diameter 2
222.4 mm
CCFWS Connection code form
01
CCSWS Connection code style
3
CCTWS Connection code type
CCM
CCUWS Connection code unit base
0
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
2500
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
SPK06000200
FamilyProducts
Cap-Type / Central Locking Adaptor
HAND Cutting direction
N - Neutral
ID Technical product number
4555248
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
3 Hole pattern (through bore) machine side or hole pattern (threaded hole) machine side or
LOC-01 CCTWS Connection code type
CCM Coromant Cap Mounting SANDVIK
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
2500
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
CCM25000103
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
IL-K-733
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
SPK Spindle nose mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0600
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SPK06000200
Name Identifying order number
FBD060CAP250SA017
OAL Overall length
60 mm
WT Weight of item
11.5 kg
