Главная Каталог продукции Toolunited 11 401-01 - Converter, rotationally symmetric DIN6987150MT5X105

DIN6987150MT5X105

DIN6987150MT5X105 DIN6987150MT5X105 DIN6987150MT5X105

DIN6987150MT5X105

Ingersoll
Артикул: 4542080
В наличии
В корзину
Описание
Характеристики
BD Body diameter
63 mm
CCFWS Connection code form
21
CCSWS Connection code style
5
CCTWS Connection code type
MKG
CCUWS Connection code unit base
8
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0050
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
SKG05001085
FamilyProducts
ISO 40/50 DIN69871A Morse Taper
HAND Cutting direction
N - Neutral
ID Technical product number
4542080
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
85.9 mm
LOC-01 CCFWS Connection code form
21
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
MKG Morse taper
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0050
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
MKG00502195
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
IL-K-1266
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05001085
LPR Protruding length
105 mm
Name Identifying order number
DIN6987150MT5X105
OAL Overall length
206.8 mm
WT Weight of item
3.4 kg
