Главная Каталог продукции Toolunited 11 401-01 - Converter, rotationally symmetric DIN208040SEMC22X52

DIN208040SEMC22X52

DIN208040SEMC22X52 DIN208040SEMC22X52 DIN208040SEMC22X52

DIN208040SEMC22X52

Ingersoll
Артикул: 4541791
В наличии
В корзину
Описание
Характеристики
CCFWS Connection code form
02
CCSWS Connection code style
0
CCTWS Connection code type
FDA
CCUWS Connection code unit base
0
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0220
DCONWS Diameter
22 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
SKG04002085
FamilyProducts
ISO 40/50 DIN2080 Combi Arbors
HAND Cutting direction
N - Neutral
ID Technical product number
4541791
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
40.4 mm
LOC-01 CCFWS Connection code form
02
LOC-01 CCSWS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-01 CCTWS Connection code type
FDA Milling arbor mounting
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0220
LOC-01 DCONWS Diameter
22 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
FDA02200200
LOC-03 CCFMS Connection code form
20
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04002085
LPR Protruding length
52 mm
LSCN Clamping length minimum
19 mm
LSCX Clamping length maximum
19 mm
Name Identifying order number
DIN208040SEMC22X52
WT Weight of item
1.3 kg
