Главная Каталог продукции Toolunited 11 401-01 - Converter, rotationally symmetric BT40MT3DRW

BT40MT3DRW

BT40MT3DRW BT40MT3DRW BT40MT3DRW

BT40MT3DRW

Ingersoll
Артикул: 4541564
В наличии
В корзину
Описание
Характеристики
BD Body diameter
40 mm
CCFWS Connection code form
11
CCSWS Connection code style
5
CCTWS Connection code type
MKG
CCUWS Connection code unit base
8
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0030
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
SKG04005085
FamilyProducts
MAS BT 40/50 Morse Taper drawbar thread
HAND Cutting direction
N - Neutral
ID Technical product number
4541564
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
43 mm
LOC-01 CCFWS Connection code form
11
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
MKG Morse taper
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0030
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
MKG00301195
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
IL-K-1259
LOC-03 CCFMS Connection code form
50
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04005085
LPR Protruding length
70 mm
Name Identifying order number
BT40MT3DRW
WT Weight of item
1.3 kg
