81512035
81512035
Артикул:
81512035
В наличии
Характеристики
BD Body diameter
45 mm
BLQ Balance quality code
G6,3/12000
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SZD
CCUWS Connection code unit base
9
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
CE - Ceratizit
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0250
DIN
SKG03005195
DLN Diameter lock nut
60 mm
FamilyProducts
SPANNZANGENFUTTER FORM A+B
HAND Cutting direction
N - Neutral
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SZD Collet adapter DIN / ISO
LOC-01 CCUWS Connection code unit base
9 non-dimensional size with coolant
LOC-01 CZCWS Connection size code
0250
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SZD02500195
LOC-03 CCFMS Connection code form
51
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0300
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG03005195
LPR Protruding length
80 mm
Name Identifying order number
81512035
OAL Overall length
128.4 mm
THSZWS Connection thread nominal size workpiece side
M48x2
