Главная Каталог продукции Toolunited 11 303-02 - Centre cutting end mill 5602R38414GM-0300L KMG406

5602R38414GM-0300L KMG406

Артикул: 5602R38414GM-0300L KMG406

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

6.5 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

AlCrN

COMPC Company code

ZCC - ZCC Cutting Tools

CRCLMFG Chip removal class mfg

P;M;K

CRCLVDI Chip removal class

1-20

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

3 mm

DCP Data chip provision

0 - Without data chip

Delivery state

SF - Made to order

DIN

ZYL00601005

DN Neck diameter

2.7 mm

F71 Number of corner designs

FamilyProducts

End mill long cutting edge

FHA Flute helix angle

41 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

KMG406

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

ID Identifying order number

5602R38414GM-0300L KMG406

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

LN Neck length

15 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYL cylindrical shank

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03 TCDCONCDMS Tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00601005

LS Shank length

43 mm

MILTTY Mill tool type ISO

H - Slotting end mill (one or more indexable insert pro cutting edge) 90°

OAL Overall length

58 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FEC - Square shoulder milling,FNU - Groove milling,FPL - Face milling,FSE - Counter-sinking,FZI - Circular milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
