Главная Каталог продукции Toolunited 11 303-02 - Centre cutting end mill 52882122

52882122

Артикул: 52882122

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

10 mm

COATN Coating

DIAMOND

COMPC Company code

CE - Ceratizit

DC Cutting diameter

12 mm

DIN

SAM01000115

DN Neck diameter

11.2 mm

F71 Number of corner designs

FamilyProducts

VHM PKD-TORUSFRÄSER

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GAMP Rake angle axial

0 Degree

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAM Screw mounting MAPAL

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0100

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAM01000115

LPR Protruding length

22 mm

Name Identifying order number

52882122

OAL Overall length

36.1 mm

RE Corner radius

1.5 mm

Working process

No working processes available

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
