Главная Каталог продукции Toolunited 11 307-01 - Non-centre cutting single row end mill MEW16-W16-10-2T

MEW16-W16-10-2T

MEW16-W16-10-2T

MEW16-W16-10-2T

Kyocera
Артикул: THN05071
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
88 Degree
A2A Clearance angle major Pos. A
0 Degree
APMX Depth of cut maximum
10 mm
AZ Plunge depth maximum
0 mm
B1A Cutting edge length Pos. A
10.9 mm
B2A Insert width Pos. A
6.6 mm
B3A Inscribed circle diameter Pos. A
6.6 mm
BD Body diameter
14.8 mm
BLDA Tool style code Position A
99
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
4 mm
CCONMS Connection count machine side
1
CICT Cutting item count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
0.8 mm
DC Cutting diameter
16 mm
Delivery state valid from
5/17/2021
DIN
ZYL01601015
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
2
FamilyProducts
MEW Lead Angle 0°Milling Cutter
GAMF Rake angle radial
-22 Degree
GAMP Rake angle axial
7 Degree
HAND Cutting direction
R - Right
ID Technical product number
THN05071
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LH Head length
25 mm
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01601015
LPR Protruding length
30 mm
LS Shank length
50 mm
LU Usable length
21 mm
MILTTY Mill tool type ISO
J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MEW16-W16-10-2T
OAL Overall length
75 mm
RPMX Rotational speed maximum
43750 1/min
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
WT Weight of item
0.135 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
