Главная Каталог продукции Toolunited 11 307-01 - Non-centre cutting single row end mill MECX32-S32-07-8T

MECX32-S32-07-8T

MECX32-S32-07-8T

MECX32-S32-07-8T

MECX32-S32-07-8T

Kyocera

Артикул: THN03666

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

80 Degree

A2A Clearance angle major Pos. A

15 Degree

APMX Depth of cut maximum

6 mm

AZ Plunge depth maximum

0.4 mm

B1A Cutting edge length Pos. A

6.7 mm

B2A Insert width Pos. A

4.6 mm

B3A Inscribed circle diameter Pos. A

4.6 mm

BD Body diameter

31 mm

BLDA Tool style code Position A

99

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

2.6 mm

CCONMS Connection count machine side

1

CICT Cutting item count

8

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D1A Corner radius Pos. A

0.8 mm

DC Cutting diameter

32 mm

Delivery state valid from

5/17/2021

DIN

ZYL03200115

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

8

FamilyProducts

MECX Lead Angle 0°Milling Cutter

GAMF Rake angle radial

0 Degree

GAMP Rake angle axial

16 Degree

HAND Cutting direction

R - Right

ID Technical product number

THN03666

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

0

ISYC Subclass

307-01 - Non-centre cutting single row end mill

KAPR Tool cutting edge angle

90 Degree

LF Functional length

130 mm

LH Head length

30 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$07

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03200115

LPR Protruding length

35 mm

LS Shank length

100 mm

LU Usable length

21.9 mm

MILTTY Mill tool type ISO

J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

MECX32-S32-07-8T

OAL Overall length

130 mm

RMPX Ramping angle maximum

0.8 Degree

RPMX Rotational speed maximum

33600 1/min

TCDCONMS ISO-tolerance class shank diameter

h7

Working process

No working processes available

WT Weight of item

0.788 kg

ZEFF Face effective cutting edge count

8

ZEFP Peripheral effective cutting edge count

8
