Главная Каталог продукции Toolunited 11 307-01 - Non-centre cutting single row end mill DMC812-S16

DMC812-S16

DMC812-S16

DMC812-S16

Kyocera
Артикул: THC05912
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
86 Degree
A2A Clearance angle major Pos. A
15 Degree
APMX Depth of cut maximum
8.5 mm
AZ Plunge depth maximum
1 mm
B1A Cutting edge length Pos. A
9.5 mm
B2A Insert width Pos. A
6.35 mm
B3A Inscribed circle diameter Pos. A
6.35 mm
BD Body diameter
11 mm
BLDA Tool style code Position A
99
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
2.38 mm
CCONMS Connection count machine side
1
CICT Cutting item count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
0 - Without coolant exit
D1A Corner radius Pos. A
0.4 mm
DC Cutting diameter
12 mm
Delivery state valid from
5/17/2021
DIN
ZYL01600105
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
1
FamilyProducts
DMC Lead Angle 0°Milling Cutter
GAMF Rake angle radial
0 Degree
GAMP Rake angle axial
5 Degree
HAND Cutting direction
R - Right
ID Technical product number
THC05912
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LF Functional length
90 mm
LH Head length
31 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$07
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01600105
LPR Protruding length
36 mm
LS Shank length
59 mm
LU Usable length
15 mm
MILTTY Mill tool type ISO
J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
DMC812-S16
OAL Overall length
90 mm
TCDCONMS ISO-tolerance class shank diameter
h7
Working process
No working processes available
WT Weight of item
0.15 kg
ZEFF Face effective cutting edge count
1
ZEFP Peripheral effective cutting edge count
1
