Главная Каталог продукции Toolunited 11 307-01 - Non-centre cutting single row end mill 15X1W063075H9R00

15X1W063075H9R00

15X1W063075H9R00 15X1W063075H9R00 15X1W063075H9R00 15X1W063075H9R00

15X1W063075H9R00

Ingersoll
Артикул: 3025046
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CICT Cutting item count
5
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DC Cutting diameter
63 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
HSK05000195
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
5
FamilyProducts
End Mill 15X1W...H9
HAND Cutting direction
R - Right
ID Technical product number
3025046
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-01 - Non-centre cutting single row end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK05000195
Name Identifying order number
15X1W063075H9R00
OAL Overall length
100 mm
RMPX Ramping angle maximum
4.7 Degree
Working process
No working processes available
WT Weight of item
1 kg
ZEFP Peripheral effective cutting edge count
5
