Главная Каталог продукции Toolunited 11 307-01 - Non-centre cutting single row end mill 12J1K040145Z4R00

12J1K040145Z4R00

12J1K040145Z4R00 12J1K040145Z4R00 12J1K040145Z4R00 12J1K040145Z4R00

12J1K040145Z4R00

Ingersoll
Артикул: 3080461
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
16 mm
CCONMS Connection count machine side
2
CICT Cutting item count
3
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
40 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
ITC04000215
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
3
FamilyProducts
End Mill 12J1K...Z
HAND Cutting direction
R - Right
ID Technical product number
3080461
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-01 - Non-centre cutting single row end mill
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ITC Ingersoll Tool connection
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03 DCONMS Diameter
49 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ITC04000215
LPR Protruding length
145 mm
Name Identifying order number
12J1K040145Z4R00
OAL Overall length
180 mm
RMPX Ramping angle maximum
3 Degree
Working process
No working processes available
WT Weight of item
1.33 kg
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
