10731079
10731079
Артикул:
10731079
В наличии
Характеристики
CCONMS Connection count machine side
1
COATN Coating / Покрытие
Ti700
COMPC Company code
CE - Ceratizit
DC Cutting diameter minimum
7.9 mm
Delivery state valid from
10/1/2021
DIN
ZYL00800105
FamilyProducts
VHM SPIRALBOHRER
FHH Flute helix hand
L - Hand of helix left
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
302-01 - Twist Drill
LCF Length chip flute
41 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0080
LOC-03 DCONMS Diameter
8 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00800105
LPR Protruding length
43 mm
LS Shank length
36 mm
LU Usable length
29 mm
Name Identifying order number
10731079
NOF Flute count
2
OAL Overall length
79 mm
SIG Point angle 1st step
140 Degree
Working process
No working processes available
