Главная Каталог продукции Toolunited 11 302-01 - Twist Drill 1010919500

1010919500

Артикул: 1010919500

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

COATN Coating

vap.

COMPC Company code

CE - Ceratizit

DC Cutting diameter minimum

19.5 mm

Delivery state valid from

10/1/2021

DIN

ZYL01950105

FamilyProducts

HSSE SPIRALBOHRER

FHH Flute helix hand

L - Hand of helix left

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

66 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0195

LOC-03 DCONMS Diameter

19.5 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01950105

LPR Protruding length

67 mm

LS Shank length

65 mm

LU Usable length

58.5 mm

Name Identifying order number

1010919500

NOF Flute count

OAL Overall length

131 mm

SIG Point angle 1st step

130 Degree

Working process

No working processes available
