Главная Каталог продукции Toolunited 11 309-06 - Pull back boring bar S40T-PDZNR15-54

S40T-PDZNR15-54

S40T-PDZNR15-54

S40T-PDZNR15-54

S40T-PDZNR15-54

Kyocera

Артикул: THC08098

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

0 Degree

B3A Inscribed circle diameter Pos. A

12.7 mm

BLDA Tool style code Position A

3

C1A Insert thickness Pos. A

4.76 mm

CEATC Tool cutting edge angle type code

P - Pull back

CEDC Cutting edge count

1

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

0 - Without coolant exit

D1A Corner radius Pos. A

0.8 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

11/10/2020

DIN

ZYL04002205

DIN CSW1

DN1504082L

DMIN Minimum bore diameter

54 mm

EPSR Insert included angle

55 Degree

FamilyProducts

KYOCERA INTERNAL TURNING TOOLHOLDER

GAMF Rake angle radial

6 Degree

GAMO Rake angle orthogonal

12 Degree

HAND Cutting direction

R - Right

HF Functional height

25 mm

ID Technical product number

THC08098

Interface codes

J6 /

Interface codes CSW1

J41 /

ISISO A Indicator for ISO cutting plate Pos.A

1

ISYC Subclass

309-06 - Pull back boring bar

KAPR Tool cutting edge angle

93 Degree

L Cutting edge length

15.504 mm

LF Functional length

300 mm

LH Head length

50 mm

LOC-03 B Shank width

39.5 mm

LOC-03 CCFMS Connection code form

22

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0400

LOC-03 DCONMS Diameter

40 mm

LOC-03 H Shank height

39 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL04002205

MIID Master insert identification

DNMG150408

MTP Clamping type code

P - Hole clamping, with straight bore

Name Identifying order number

S40T-PDZNR15-54

OAL Overall length

325 mm

STDDES Standard designation

S40T-PDZNR15-54

SX Shank cross section shape code

31 - (left) Round shank

THSC Tool holder shape code

A - offset shank design

WF Functional width

27 mm

Working process

No working processes available
