Главная Каталог продукции Toolunited 11 309-06 - Pull back boring bar 70733212

70733212

Артикул: 70733212

В наличии

В корзину

Описание

Характеристики

CEATC Tool cutting edge angle type code

P - Pull back

CEDC Cutting edge count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

CE - Ceratizit

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

Delivery state valid from

10/1/2021

DIN

ZYL01202205

DMIN Minimum bore diameter

16 mm

FamilyProducts

MAXILOCK S KLEMMHALTER INNEN

HAND Cutting direction

L - Left

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

ISYC Subclass

309-06 - Pull back boring bar

KAPR Tool cutting edge angle

93 Degree

LF Functional length

125 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03 H Shank height

11.5 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01202205

Name Identifying order number

70733212

OAL Overall length

137 mm

STDDES Standard designation

A12KSDXCL07

SX Shank cross section shape code

10 - Round shank

WF Functional width

9 mm

Working process

DDI - Internal turning
