Главная Каталог продукции Toolunited 11 306-01 - Twist drill for indexable inserts S50-DRW0670M-3-06

S50-DRW0670M-3-06

S50-DRW0670M-3-06

S50-DRW0670M-3-06

S50-DRW0670M-3-06

Kyocera

Артикул: THD11036

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

80 Degree

A1B Cutting edge angle major Pos. B

80 Degree

A2A Clearance angle major Pos. A

7 Degree

A2B Clearance angle major Pos. B

7 Degree

B1A Cutting edge length Pos. A

6.515 mm

B1B Cutting edge length Pos. B

6.515 mm

B3A Inscribed circle diameter Pos. A

9.525 mm

B3B Inscribed circle diameter Pos. B

9.525 mm

BD Body diameter 1st step

65 mm

BLDA Tool style code Position A

7

BLDB Tool style code Position B

7

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

3.97 mm

C1B Insert thickness Pos. B

3.97 mm

CCONMS Connection count machine side

1

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D1A Corner radius Pos. A

0.8 mm

D1B Corner radius Pos. B

0.8 mm

DC Cutting diameter minimum

67 mm

DCONMSUD Mounting diameter upper dimension

0 mm

Delivery state valid from

11/13/2020

DIN

ZYL05001115

FamilyProducts

MagicDrill type DRW Indexable Insert Drill

HAND Cutting direction

R - Right

ID Technical product number

THD11036

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

1

ISISO B Indicator for ISO cutting plate Pos.B

1

ISYC Subclass

306-01 - Twist drill for indexable inserts

LOC-02 BI Block index

2

LOC-02 MIID Master insert identification

WCMT06T3083R

LOC-02-Connection-codes

J44 / J441 - Insert (Unknown 02)

LOC-02-DIN

WC06T3083R

LOC-03 CCFMS Connection code form

11

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0500

LOC-03 DCONMS Diameter

50 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$07

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL05001115

LPR Protruding length

252 mm

LS Shank length

69 mm

LU Usable length

201 mm

Name Identifying order number

S50-DRW0670M-3-06

NOF Flute count

1

NUMBER INSERTS INSIDE Number of inserts inside

1

NUMBER INSERTS OUTSIDE Number of inserts outside

3

OAL Overall length

321 mm

SIG Point angle 1st step

174 Degree

TCDCONMS ISO-tolerance class shank diameter

h7

Working process

No working processes available

WT Weight of item

4.85 kg
