Главная Каталог продукции Toolunited 11 306-01 - Twist drill for indexable inserts S40-DRZ4998-15

S40-DRZ4998-15

S40-DRZ4998-15

Kyocera

Артикул: THD02900

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

87 Degree

A1B Cutting edge angle major Pos. B

87 Degree

A2A Clearance angle major Pos. A

7 Degree

A2B Clearance angle major Pos. B

7 Degree

ANGLE BOND Angle bond

30 Degree

B1A Cutting edge length Pos. A

15.3 mm

B1B Cutting edge length Pos. B

15.5 mm

B3A Inscribed circle diameter Pos. A

17.8 mm

B3B Inscribed circle diameter Pos. B

17.8 mm

BD Body diameter 1st step

47.75 mm

BLDA Tool style code Position A

99

BLDB Tool style code Position B

99

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

4.76 mm

C1B Insert thickness Pos. B

4.76 mm

CCONMS Connection count machine side

1

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D1A Corner radius Pos. A

0.8 mm

D1B Corner radius Pos. B

0.8 mm

DC Cutting diameter minimum

49 mm

DCONMSUD Mounting diameter upper dimension

0 mm

Delivery state valid from

11/13/2020

DF Flange diameter

60 mm

DIN

ZYL04001115

FamilyProducts

MagicDrill type DRZ Indexable Insert Drill

HAND Cutting direction

R - Right

ID Technical product number

THD02900

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

0

ISISO B Indicator for ISO cutting plate Pos.B

0

ISYC Subclass

306-01 - Twist drill for indexable inserts

LCF Length chip flute

102 mm

LENGTH BOND Length bond

27.1 mm

LOC-03 CCFMS Connection code form

11

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0400

LOC-03 DCONMS Diameter

40 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$07

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL04001115

LPR Protruding length

135 mm

LS Shank length

69 mm

LU Usable length

98 mm

Name Identifying order number

S40-DRZ4998-15

NOF Flute count

1

NUMBER INSERTS INSIDE Number of inserts inside

1

NUMBER INSERTS OUTSIDE Number of inserts outside

1

OAL Overall length

204 mm

SIG Point angle 1st step

166 Degree

TCDCONMS ISO-tolerance class shank diameter

h7

Working process

No working processes available

WT Weight of item

1.985 kg
