S20-CH10-DRA
S20-CH10-DRA
Артикул:
THD12003
В наличии
Характеристики
BDX Body diameter maximum
39 mm
BLDB Tool style code Position B
99
BMC Body material code
S - Solid steel
CCF Connection code form
01
CCONMS Connection count machine side
1
CCS Connection code style
5
CCT Connection code type
ZYL
CCU Connection code unit base
1
CEDC Cutting edge count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
CZC Connection size code
0100
DCONMSUD Mounting diameter upper dimension
0 mm
DCX Cutting diameter 1st step maximum
10 mm
Delivery state valid from
11/13/2020
DF Flange diameter
39 mm
DIN
ZYL02000115
FamilyProducts
MagicDrill type DRA Attachment
HAND Cutting direction
R - Right
ID Technical product number
THD12003
Interface codes
J6 /
ISISO B Indicator for ISO cutting plate Pos.B
0
ISYC Subclass
306-09 - Step drill for adjustable solid drill
LCF Length chip flute
30 mm
LOC-01 BI Block index
1
LOC-01 CCF Connection code form
01
LOC-01 CCS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCT Connection code type
ZYL cylindrical shank
LOC-01 CCU Connection code unit base
1 Metric with coolant
LOC-01 CZC Connection size code
0100
LOC-01 MIID Master insert identification
CT12T3-45DA
LOC-01-Connection-codes
J43 / J431 - interface code, workpiece side, for drilling heads or pilot drills
LOC-01-DIN
ZYL01000115
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000115
LPR Protruding length
58 mm
LS Shank length
52 mm
Name Identifying order number
S20-CH10-DRA
NOF Flute count
2
NUMBER INSERTS OUTSIDE Number of inserts outside
1
OAL Overall length
110 mm
SIG Point angle 1st step
90 Degree
Working process
No working processes available
WT Weight of item
0.439 kg
