ZNMV 141008Y-BF TT8115

Артикул: 6330398

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

0 - Without chip breaker

COATN Coating

TiCN+Al2O3+TiN

COMPC Company code

IL - Ingersoll

Delivery state

LL - Stock limited

DIN

IL-WSP-4333

EPSR Insert included angle

35 Degree

FamilyProducts

insert, Negative rhombic inserts with 35° corner angle

GRDMFG Grade manufacturers designation

TT8115

GRDPRIO Standard designation of the grade main application

P05-P20

IC Inscribed circle diameter

10.5 mm

ID Technical product number

6330398

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-00 - Regular Insert unspecified

LE Cutting edge effective length

0.5 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

IL-WSP-4333

Name Identifying order number

ZNMV 141008Y-BF TT8115

RE Corner radius

0.8 mm

S Insert thickness

10 mm

S1 Insert thickness total

10 mm

TCINS Tolerance class insert

Working process

No working processes available
