MNHU090408R-M IN2530
MNHU090408R-M IN2530
Артикул:
6172877
В наличии
Характеристики
AN Clearance angle major
0 Degree
CB Chip breaker face count
2 - With chip breaker on both sides
COATN Coating
TiAlN+TiN
COMPC Company code
IL - Ingersoll
D1 Fixing hole diameter
4.2 mm
Delivery state
LL - Stock limited
DIN
MN0904 5R
EPSR Insert included angle
76 Degree
FamilyProducts
insert, four-edged, positive geometry with R0,8
GRD2ND Standard designation of the grade 2nd application
M15-M30
GRD3RD Standard designation of the grade 3rd application
K20-K40
GRDMFG Grade manufacturers designation
IN2530
GRDPRIO Standard designation of the grade main application
P20-P40
IC Inscribed circle diameter
8.6 mm
ID Technical product number
6172877
IFS Insert mounting style code
5 - Special production, e.g. trough clamping
IH Insert hand
R - Right
Interface codes
J6 /
ISISO ISO property
0
ISYC Subclass
201-00 - Regular Insert unspecified
L Cutting edge length
8.28 mm
LE Cutting edge effective length
8 mm
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
MN0904 5R
Name Identifying order number
MNHU090408R-M IN2530
RE Corner radius
0.8 mm
S Insert thickness
5.9 mm
S1 Insert thickness total
5.9 mm
STDDES Standard designation
MNHU090408R
TCINS Tolerance class insert
H
W1 Insert width
8.6 mm
Working process
No working processes available
