Главная Каталог продукции Toolunited 11 201-00 - Regular Insert unspecified 50449600

50449600

Артикул: 50449600

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

BS Wiper edge length

1.74 mm

CECC Cutting edge condition code

F - Sharpedged

COATN Coating

H216T

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

5.5 mm

Delivery state valid from

10/1/2021

FamilyProducts

HM-FRÄSWENDEPLATTE

GRD2ND Standard designation of the grade 2nd application

HW-K20

GRDPRIO Standard designation of the grade main application

HW-N20

IC Inscribed circle diameter

12.7 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-00 - Regular Insert unspecified

L Cutting edge length

7.5 mm

Name Identifying order number

50449600

RE Corner radius

1 mm

S Insert thickness

4.76 mm

TCINS Tolerance class insert

Working process

No working processes available
