70255654
70255654
Артикул:
70255654
В наличии
Характеристики
AN Clearance angle major
7 Degree
CBMD Chip breaker manufacturers designation
-23P
CECC Cutting edge condition code
F - Sharpedged
COATN Coating
H216T
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
2.8 mm
Delivery state valid from
10/1/2021
EPSR Insert included angle
80 Degree
FamilyProducts
HM-DREHWENDEPLATTE
GRDPRIO Standard designation of the grade main application
HW-N15
IC Inscribed circle diameter
6.35 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-03 - Rhombic insert
L Cutting edge length
6.4 mm
Name Identifying order number
70255654
RE Corner radius
0.4 mm
S Insert thickness
2.38 mm
TCINS Tolerance class insert
G
Working process
No working processes available
