70254462
70254462
Артикул:
70254462
В наличии
Характеристики
AN Clearance angle major
7 Degree
CBMD Chip breaker manufacturers designation
-27
CECC Cutting edge condition code
F - Sharpedged
COATN Coating
AMZ
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
5.5 mm
EPSR Insert included angle
80 Degree
FamilyProducts
HM-DREHWENDEPLATTE
GRDPRIO Standard designation of the grade main application
HC-N20
IC Inscribed circle diameter
12.7 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-03 - Rhombic insert
L Cutting edge length
12.9 mm
Name Identifying order number
70254462
RE Corner radius
0.4 mm
S Insert thickness
4.76 mm
TCINS Tolerance class insert
G
Working process
No working processes available
