70101762

Артикул: 70101762

В наличии

В корзину

Описание

Характеристики

CBMD Chip breaker manufacturers designation

-CF

CECC Cutting edge condition code

E - Rounded

COATN Coating

TCC410

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

5.16 mm

EPSR Insert included angle

80 Degree

FamilyProducts

CERMET-DREHWENDEPLATTE

GRDPRIO Standard designation of the grade main application

HT-P10

IC Inscribed circle diameter

12.7 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-03 - Rhombic insert

L Cutting edge length

12.9 mm

Name Identifying order number

70101762

RE Corner radius

1.2 mm

S Insert thickness

4.76 mm

TCINS Tolerance class insert

Working process

No working processes available
