76177006

Артикул: 76177006

В наличии

В корзину

Описание

Характеристики

CBMD Chip breaker manufacturers designation

-TFQ

CECC Cutting edge condition code

E - Rounded

COATN Coating / Покрытие

CTEP110

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

3.81 mm

Delivery state valid from

10/1/2021

EPSR Insert included angle

80 Degree

FamilyProducts

CERMET-DREHWENDEPLATTE

GRDPRIO Standard designation of the grade main application

HT-P10

IC Inscribed circle diameter

9.52 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

L Cutting edge length

6.5 mm

Name Identifying order number

76177006

RE Corner radius

0.8 mm

S Insert thickness

4.76 mm

TCINS Tolerance class insert

Working process

No working processes available
