7531101609
7531101609
Артикул:
7531101609
В наличии
Характеристики
CBMD Chip breaker manufacturers designation
-FMS
CECC Cutting edge condition code
E - Rounded
COATN Coating
CT-P15
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
5.16 mm
Delivery state valid from
10/1/2021
EPSR Insert included angle
80 Degree
FamilyProducts
HM-DREHWENDEPLATTE
GRD2ND Standard designation of the grade 2nd application
HC-K25
GRD3RD Standard designation of the grade 3rd application
HC-M10
GRDPRIO Standard designation of the grade main application
HC-P15
IC Inscribed circle diameter
12.7 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-07 - Trigon insert
L Cutting edge length
8.6 mm
Name Identifying order number
7531101609
RE Corner radius
0.4 mm
S Insert thickness
4.76 mm
TCINS Tolerance class insert
M
Working process
No working processes available
