Артикул:
71405376
В наличии
Характеристики
BN Face land width
0.14 mm
CECC Cutting edge condition code
S - Chamfered and rounded
COATN Coating
CTBH40C
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
5.13 mm
Delivery state valid from
10/1/2021
EPSR Insert included angle
80 Degree
FamilyProducts
PCBN-DREHWENDEPLATTE
GRDPRIO Standard designation of the grade main application
BC-H40
IC Inscribed circle diameter
12.7 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-07 - Trigon insert
L Cutting edge length
8.5 mm
LE Cutting edge effective length
2.5 mm
Name Identifying order number
71405376
NOI Insert index count
6
RE Corner radius
0.8 mm
S Insert thickness
4.76 mm
TCE Tipped cutting edge code
M
TCINS Tolerance class insert
G
Working process
No working processes available
