1082125502

Артикул: 1082125502

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

8 Degree

CBMD Chip breaker manufacturers designation

-02

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating

BK6440

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

2.85 mm

Delivery state valid from

10/1/2021

EPSR Insert included angle

84 Degree

FamilyProducts

HM-BOHRWENDEPLATTE

IC Inscribed circle diameter

8 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

L Cutting edge length

5.3 mm

Name Identifying order number

1082125502

RE Corner radius

0.4 mm

S Insert thickness

3.8 mm

Working process

No working processes available
