Главная Каталог продукции Toolunited 11 304-10 - Angular milling cutter 50362445

50362445

Артикул: 50362445

В наличии

В корзину

Описание

Характеристики

COATN Coating

ohne

COMPC Company code

CE - Ceratizit

DC Cutting diameter

100 mm

Delivery state valid from

10/1/2021

DIN

FDA02701200

FamilyProducts

HSS WINKELSTIRNFRÄSER

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GAMP Rake angle axial

2 Degree

Interface codes

J6 /

ISYC Subclass

304-10 - Angular milling cutter

KAPR Tool cutting edge angle

45 Degree

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Connection code type

FDA Milling arbor mounting

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0270

LOC-03 DCONMS Diameter

27 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA02701200

Name Identifying order number

50362445

OAW Overall width

28 mm

Working process

No working processes available

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
