ROHX2005 YBG202

Артикул: ROHX2005 YBG202

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

18 Degree

COATN Coating / Покрытие

nc-TiAlN

COMPC Company code

ZCC - ZCC Cutting Tools

D1 Fixing hole diameter

5 mm

Delivery state valid from

0.2 kg

DIN

ZCC-RO2005

FamilyProducts

RO** positive insert

GRD2ND Standard designation of the grade 2nd application

M10-M25

GRDMFG Grade manufacturers designation

YBG202

GRDPRIO Standard designation of the grade main application

P10-P30

IC Inscribed circle diameter

20 mm

ID Identifying order number

ROHX2005 YBG202

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-10 - Round insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

ZCC-RO2005

M M-dimension

20 mm

S Insert thickness

2.5 mm

S1 Insert thickness total

5 mm

TCINS Tolerance class insert

Working process

No working processes available
