PMX16HM-17000-32N1

Артикул: 02925843

В наличии

В корзину

Описание

Характеристики

COMPC Company code

SO - SECO Tools

DC Cutting diameter minimum

32.5 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter 1st step maximum

60.5 mm

Delivery state valid from

3/14/2020

DIN

ZYL03200105

FamilyProducts

PMX16HM-17000-32N1

HAND Cutting direction

R - Right

ID Technical product number

02925843

Interface codes

J6 / J61

ISO

ZYL01G3200h$06

ISYC Subclass

312-00 - Reamer with indexable inserts unspecified

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03 ISO

ZYL01G3200h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03200105

LS Shank length

61 mm

LU Usable length

170 mm

Name Identifying order number

PMX16HM-17000-32N1

OAL Overall length

231 mm

Working process

No working processes available

WT Weight of item

1.2891 kg
