JCO710200D4R250.3Z6

JCO710200D4R250.3Z6 JCO710200D4R250.3Z6 JCO710200D4R250.3Z6 JCO710200D4R250.3Z6

JCO710200D4R250.3Z6

SECO Tools
Артикул: 02905377
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
80 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
20 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
ZYL02001005
F71 Number of corner designs
1
FamilyProducts
JCO710200D4R250.3Z6
FHA Flute helix angle
35 Degree
FHH Flute helix hand
R - Hand of helix right
GAMF Rake angle radial
35 Degree
GAMP Rake angle axial
12 Degree
HAND Cutting direction
R - Right
ID Technical product number
02905377
Interface codes
J6 / J61
ISO
ZYL10G2000h$06
ISYC Subclass
303-01 - Non-centre cutting end mill
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03 ISO
ZYL10G2000h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02001005
LS Shank length
50 mm
Name Identifying order number
JCO710200D4R250.3Z6
OAL Overall length
146 mm
RE Corner radius
2.5 mm
Working process
No working processes available
WT Weight of item
0.277 kg
ZEFP Peripheral effective cutting edge count
6
