F2252.B.250.Z16.19.R000

Артикул: 5019792

В наличии

В корзину

Описание

Характеристики

ADJBY Adjustment property

0 - Adjustment not possible

BD Body diameter

244.5 mm

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

W - Walter

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2023

DIN

FDA06000100

F23 Number of mounting layers

FamilyProducts

Basic bodies F2252

HAND Cutting direction

R - Right

ID Technical product number

5019792

Interface codes

J6 / J61

ISISO A Indicator for ISO cutting plate Pos.A

ISO

FDA01G6000$$$$

ISYC Subclass

308-06 - Half-side slot milling cutter

LOC-03 CCFMS Form

LOC-03 CCSMS Style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Type

FDA Milling arbor mounting

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0600

LOC-03 DCONMS Diameter

60 mm

LOC-03 ISO

FDA01G6000$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA06000100

MILTTY Mill tool type ISO

E - Disc mill - one side cutting

Name Identifying order number

F2252.B.250.Z16.19.R000

OAL Overall length

19 mm

Working process

No working processes available

WT Weight of item

3 kg
