Главная Каталог продукции Toolunited 10 E930658341295

E930658341295

Артикул: 00039126

В наличии

В корзину

Описание

Характеристики

BD Body diameter 2

50 mm

BLQ Balance quality code

G6.3

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

COMPC Company code

SO - SECO Tools

CZCWS Connection size code

0120

DCONWS Diameter

12 mm

DCONXWS Connection diameter max

12 mm

DCP Data chip provision

1 - With data chip

Delivery state valid from

3/14/2020

DIN

HSK10000185

FamilyProducts

E930658341295

HAND Cutting direction

N - Neutral

ID Technical product number

00039126

Interface codes

J6 / J61

ISO

HSK01C1000$$$$

ISYC Subclass

401-01 - Converter, rotationally symmetric

LB Body length 1

40 mm

LF Functional length

58 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

0 Metric

LOC-01 CZCWS Connection size code

0120

LOC-01 DCONWS Diameter

12 mm

LOC-01 DCONXWS Connection diameter max

12 mm

LOC-01 ISO

ZYL01G1200****

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL01200105

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

HSK Hollow taper shank

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

1000

LOC-03 ISO

HSK01C1000$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HSK10000185

LPR Protruding length

95 mm

Name Identifying order number

E930658341295

OAL Overall length

145 mm

TA Taper angle

30 Degree

WT Weight of item

2.49 kg

Диаметр корпуса (BD) / Body diameter (BD)

32 mm
