Главная Каталог продукции Toolunited 10 C4-391.5872-16060

C4-391.5872-16060

Артикул: 02532866

В наличии

В корзину

Описание

Характеристики

BD Body diameter

27 mm

BLQ Balance quality code

G6.3

COMPC Company code

SO - SECO Tools

DCONWS Diameter

0.5 mm

DCONXWS Connection diameter max

10 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

3/14/2020

DIN

CCS00400185

FamilyProducts

C4-391.5872-16060

HAND Cutting direction

N - Neutral

ID Technical product number

02532866

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LB Body length 1

23.3 mm

LF Functional length

60 mm

LOC-01 DCONWS Diameter

0.5 mm

LOC-01 DCONXWS Connection diameter max

10 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0040

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS00400185

LPR Protruding length

60 mm

Name Identifying order number

C4-391.5872-16060

OAL Overall length

84 mm

THSZWS Connection thread nominal size workpiece side

WT Weight of item

0.37 kg
