Главная Каталог продукции Toolunited 10 405-08 - Cylindrical clamping sleeve 309582 6

309582 6

309582 6 309582 6 309582 6

309582 6

Hoffmann Group
Артикул: 309582 6
В наличии
В корзину
Описание
Характеристики
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
0
COATN Coating
0
COLST Collet slot type
2 - On two side
COMPC Company code
HOG - Hoffmann Group
CZCWS Connection size code
0060
DCB Connection bore diameter
6 mm
DIN
ZYL02000105
FamilyProducts
Collet for slim heavy-duty chuck
Interface codes
J6 /
ISYC Subclass
405-08 - Cylindrical clamping sleeve
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0060
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL00600105
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000105
LSC Clamping length
6 mm
Name Identifying order number
309582 6
OAL Overall length
55 mm
SEALP Sealing
0 - Without sealing
SZID Size identification
32
WT Weight of item
0.3 kg
