Главная Каталог продукции Toolunited 10 405-01 - Double angle collet 567225045

567225045

Артикул: 02828347

В наличии

В корзину

Описание

Характеристики

BD Body diameter

26 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

COMPC Company code

SO - SECO Tools

CZCWS Connection size code

0045

DCBN Connection bore diameter minimum

4.5 mm

DCBX Connection bore diameter maximum

4.5 mm

Delivery state valid from

3/14/2020

DIN

SZD02500285

FamilyProducts

567225045

ID Technical product number

02828347

Interface codes

J6 /

ISYC Subclass

405-01 - Double angle collet

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

0 Metric

LOC-01 CZCWS Connection size code

0045

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SZD Collet adapter DIN / ISO

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0250

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SZD02500285

Name Identifying order number

567225045

OAL Overall length

34 mm

SEALP Sealing

0 - Without sealing

STDLET Standard letter to the standard number

STDNO Standard

DIN6499

TA Taper angle 1

16 Degree

TA Taper angle 2

30 Degree

WT Weight of item

0.07 kg
