Главная Каталог продукции Toolunited 10 401-04 - Reducer, primary design 205995

205995

Артикул: 205995

В наличии

В корзину

Описание

Характеристики

BD Body diameter

25 mm

BD Body diameter 2

27.1 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SJ - Schunk

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0625

DCINTF Interference cutting diameter

24.5 mm

DCONWS Diameter

15.875 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

ZYL07500135

FamilyProducts

TRIBOS SVL-3/4" Ø5/8"x6"

HAND Cutting direction

N - Neutral

Interface codes

J6 /

ISYC Subclass

401-04 - Reducer, primary design

LB Body length 1

45 mm

LB Length 2

54.9 mm

LF Functional length

51.9 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

3 Inch with coolant

LOC-01 CZCWS Connection size code

0625

LOC-01 DCONWS Diameter

15.875 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL06250135

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

3 Inch with coolant

LOC-03 CZCMS Connection size code

0750

LOC-03 DCONMS Diameter

19.05 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL07500135

LPR Protruding length

99.9 mm

LSCN Clamping length minimum

38 mm

LSCX Clamping length maximum

48 mm

Name Identifying order number

205995

OAL Overall length

152.4 mm

TA Taper angle

45 Degree

WT Weight of item

0.33 kg
