Главная Каталог продукции Toolunited 10 401-04 - Reducer, primary design 205614

205614

Артикул: 205614

В наличии

В корзину

Описание

Характеристики

BD Body diameter

28 mm

BD Body diameter 2

30.1 mm

BD Body diameter 3

32 mm

BHTA Body half taper angle 2

89 Degree

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SJ - Schunk

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0180

DCINTF Interference cutting diameter

27.5 mm

DCONWS Diameter

18 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

ZYL03200115

FamilyProducts

TRIBOS S SVL-32 Ø18x150

HAND Cutting direction

N - Neutral

Interface codes

J6 /

ISYC Subclass

401-04 - Reducer, primary design

LB Body length 1

45 mm

LB Length 2

5 mm

LB Length Body diameter 3

35 mm

LF Functional length

42 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0180

LOC-01 DCONWS Diameter

18 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL01800115

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03200115

LPR Protruding length

90 mm

LSCN Clamping length minimum

38 mm

LSCX Clamping length maximum

48 mm

Name Identifying order number

205614

OAL Overall length

150 mm

TA Taper angle

45 Degree

WT Weight of item

0.65 kg
