Главная Каталог продукции Toolunited 10 401-02 - Converter, stationary 216208

216208

Артикул: 216208

В наличии

В корзину

Описание

Характеристики

A1 CHA Chamfer angle at length 1

30 Degree

A1 CHW Chamfer width at length 1

2.6 mm

BD Body diameter

64 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SJ - Schunk

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0320

DCINTF Interference cutting diameter

59.6 mm

DCONWS Diameter

32 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DF Flange diameter

85 mm

DIN

ZYV04000115

FamilyProducts

TENDO Turn VDI40 Ø32x86

HAND Cutting direction

N - Neutral

Interface codes

J6 /

ISYC Subclass

401-02 - Converter, stationary

LB Body length 1

64 mm

LF Functional length

14.5 mm

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0320

LOC-01 DCONWS Diameter

32 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL03200115

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYV cylindrical shank VDI type (serrated)

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0400

LOC-03 DCONMS Diameter

40 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYV04000115

LPR Protruding length

86 mm

LSCX Clamping length maximum

71.5 mm

Name Identifying order number

216208

OAL Overall length

149 mm

TA Taper angle

7.5 Degree

WT Weight of item

2.8 kg
