Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric HSKA125-SFR0.750-6.250-F6

HSKA125-SFR0.750-6.250-F6

HSKA125-SFR0.750-6.250-F6 HSKA125-SFR0.750-6.250-F6 HSKA125-SFR0.750-6.250-F6 HSKA125-SFR0.750-6.250-F6

HSKA125-SFR0.750-6.250-F6

Seco
Артикул: 03252959
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
2 - Axial adjustment possible
BD Body diameter
44 mm
BD Body diameter 2
53 mm
BD Body diameter 3
57.75 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
2
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0750
DCONWS Diameter
19.05 mm
DCP Data chip provision
1 - With data chip
DIN
HSK12500185
FamilyProducts
HSKA125-SFR0.750-6.250-F6
HAND Cutting direction
N - Neutral
ID Technical product number
03252959
Interface codes
J6 / J61
ISO
HSK01C1250$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
80 mm
LB Length 2
111.49 mm
LF Functional length
117.75 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
2 Inch
LOC-01 CZCWS Connection size code
0750
LOC-01 DCONWS Diameter
19.05 mm
LOC-01 ISO
ZYL01R7500****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL07500125
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
1250
LOC-03 ISO
HSK01C1250$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK12500185
LPR Protruding length
158.75 mm
LSCX Clamping length maximum
41 mm
Name Identifying order number
HSKA125-SFR0.750-6.250-F6
OAL Overall length
221.75 mm
TA Taper angle
4.5 Degree
WT Weight of item
0 kg
