Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric HSKA100-PMC0.750-3.750

HSKA100-PMC0.750-3.750

HSKA100-PMC0.750-3.750 HSKA100-PMC0.750-3.750 HSKA100-PMC0.750-3.750 HSKA100-PMC0.750-3.750

HSKA100-PMC0.750-3.750

Seco
Артикул: 03211212
В наличии
В корзину
Описание
Характеристики
BD Body diameter
49 mm
BLQ Balance quality code
PB
CCFWS Connection code form
04
CCSWS Connection code style
5
CCTWS Connection code type
SZC
CCUWS Connection code unit base
9
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0750
DCONWS Diameter
19.05 mm
DCONXWS Connection diameter max
19.05 mm
DCP Data chip provision
1 - With data chip
DIN
HSK10000185
FamilyProducts
HSKA100-PMC0.750-3.750
HAND Cutting direction
N - Neutral
ID Technical product number
03211212
Interface codes
J6 / J61
ISO
HSK01C1000$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
66.243 mm
LOC-01 CCFWS Connection code form
04
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SZC Collet adapter SANDVIK Coromant
LOC-01 CCUWS Connection code unit base
9 non-dimensional size with coolant
LOC-01 CZCWS Connection size code
0750
LOC-01 DCONWS Diameter
19.05 mm
LOC-01 DCONXWS Connection diameter max
19.05 mm
LOC-01 ISO
SZC04R7500****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SZC07500495
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
1000
LOC-03 ISO
HSK01C1000$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK10000185
LPR Protruding length
95.25 mm
Name Identifying order number
HSKA100-PMC0.750-3.750
OAL Overall length
145.263 mm
RPMX Rotational speed maximum
15000 1/min
WT Weight of item
2.773 kg
